恒流光源控制器
WLPI3SC-15W-xxMA-5-2 |
WLPI3SC-30W-xxMA-5-2 |
WLPI3SC-15W-xxMA-24-2 |
WLPI3SC-30W-xxMA-24-2 |
WLPI3SC-45W-xxMA-24-2 |
WLPI3SC-65W-xxMA-24-2 |
WLPI3SC-125W-xxMA-24-2 |
WLPI3SC-15W-xxMA-5-2
参 数 表
Model | WLPI3SC-15W-xxMA-5-2 |
Input Power Supply | AC85~264V 50Hz/60Hz |
Light Channel(s) | 2 channels |
Output/per channel(xx) | DC350mA/500mA/700mA/1000mA/1500mA/2000mA/2500mA/3000mA |
Rated capacity | 15W max. for 2 channals total |
Intensity Control Mode | Constant current control,256 levels/by panel key or RS-232C |
Ext.On/Off Conditions | Yes |
Operating Conditions | 0 to 40℃,70%/RH |
Cooling Method | Natural air-cooling |
Weight | 620g |
Dimension | W120×D110×H90 mm |
Case material | AL |
